Design your custom maze puzzle box in Fusion 360. In this tutorial, we’ll use Fusion 360’s new Emboss feature to wrap the maze sketch around a cylinder.

We’ll discuss clearance, using PI, and other Fusion 360 tricks. Be sure to download the demo files at the link below.

The most reliable 3D Printer (for serious hobbyists) - https://bit.ly/kevins-printer

TIMESTAMPS
0:00 - Create a maze puzzle box in Fusion 360
0:46 - Creating components and cylinder
2:26 - Creating the Emboss template
3:56 - Generating a custom maze
5:42 - Inserting the SVG maze into Fusion 360
7:04 - Wrapping the maze with the Emboss feature
8:15 - Cleaning the top and creating the base
10:56 - Creating the cap with CLEARANCE
13:08 - Creating the notch (very important)
15:30 - Checking the notch and adding chamfers
16:49 - Adding fillets to all the edges
17:57 - Creating triangle indicators
18:25 - Double-checking for interference
18:39 - Save as STL (yay, ready to print!)
