Let's talk about Electronic Mag Locks! In today's video we're taking a look at how we used electronic mag locks on all ten of the drawers in our van. We'll look at my choice for the magnets, micro-controller, driver board, and the ESPHome YAML configuration used to make it all work! As as bonus we look at the 3D printed case and custom aluminum mounting bracket I made to complete the setup.

🚨 Mag Lock Mounting Brackets now FOR SALE!
https://marketplace.sendcutsend.com/p/CS70N307/magnetic-drawer-lock-mounting-bracket

https://www.instagram.com/mikegoubeaux/

Setting up Home Assistant Guide: https://youtu.be/q5HSJXHkqEs
Setting up ESPHome Guide: https://youtu.be/LtwPP78IBjI

📔 RESOURCES

ESPHome: https://esphome.io
ESPHome Switch: https://esphome.io/components/switch/
ESPHome Lock: https://esphome.io/components/lock/
ESPHome Template Lock: https://esphome.io/components/lock/template
ESPHome Web Server: https://esphome.io/components/web_server.html
ESPHome Status Light: https://esphome.io/components/status_led.html
ESPHome If Action: https://esphome.io/automations/actions.html#if-action
ESPHome Switch Lambdas: https://esphome.io/components/switch/#switch-lambda-calls

DOWNLOAD my ESPHome YAML configuration: https://github.com/SmartyVan/MagLocks/blob/main/mag-locks.yaml

Wiring Diagram: https://github.com/SmartyVan/MagLocks/blob/main/Mag%20Lock%20Wire%20Diagram.png

Fritzing wiring diagrams: https://fritzing.org

SendCutSend: https://bit.ly/smartyvan



🛒 PRODUCTS

Mag Lock Mounting Brackets: https://marketplace.sendcutsend.com/p/CS70N307/magnetic-drawer-lock-mounting-bracket
Mag Locks: https://amzn.to/40yoB59
ESP8266 (D1 Mini): https://amzn.to/3ZOjNbn
PWM 4x MOSFET Board: https://amzn.to/3NBOadz
4x Relay Board: https://amzn.to/3NEJ8gr
6-24v to 5v Step-Down Regulators: https://amzn.to/3YjVteU
12/24 to 5v USB-C Converter: https://amzn.to/3YfTFUi
Micro USB pigtails: https://amzn.to/4dW82TB
USB-C pigtails: https://amzn.to/4hwqsxk

Home Assistant hardware I'm using:
Raspberry Pi 4 8GB Ram: https://amzn.to/4edmYh3
SanDisk MAX ENDURANCE 128GB: https://amzn.to/4eKNKgJ

New Raspberry Pi 5:
Raspberry Pi 5 8GB RAM Kit: https://amzn.to/4eE7y5e


DISCLAIMER: This video and description contains affiliate links, which means that if you click on one of the product links, I’ll receive a small commission. This helps us keep making content! Thanks so much.


0:00 Intro - Mag Locks!
0:23 Mag Locks Demo
1:18 Magnet Choice
3:21 Making the Magnet Smart
5:04 Wiring the Components
7:52 ESPHome YAML
13:17 Setting up the Locks in Home Assistant
14:11 Creating Redundancy
15:37 Mounting the Locks
16:31 Wrapping Up
